 Vanguard Performance Line Direct Vent Gas Fireplace Systems
Vanguard
direct vent fireplaces feature brass accent trim and heat circulating
louvers with dancing yellow flames and ember materials.
Low Installation Costs .. No Chimney is Required.
Direct Vent Fireplaces do not affect indoor air quality and are ideally
suited for today's energy efficient, tightly constructed homes.
The Performance Line Series accept 5" x 8" Desa vent piping.
The Performance Line Fireplaces Include:
- Split oak ceramic fiber gas logs with charred features and glowing highlights
- 3 tiered random flame pattern with glowing ember bed burner
- New York and California only allow installation of electronic ignition models
- Built on the proven strengths of the 45 degree slant back design
- Hinged tool-less entry glass door for painless installation, operation, and maintenance
- Rolled louvers
- Flex gas line
- Shut off valve
- Pre-wired electrical "J" box to ensure quality, performance, safety, and convenience
- 1/2" flare connection
- C.S.A. Approved ANSI Z21.88 / C.S.A. 2.33
|
|
42" Performance Line Upgradeable Direct Vent Fireplaces
|
|
|
|
|
Accepts 5" x 8" Piping
|
| Model |
Fuel Type |
Description |
|
VVC42N1
| Natural
Gas
| 42" Millivolt 23-31,000 BTU Input Direct Vent Fireplace With Black Metal Interior |
|
VVC42P1
| Propane
| 42" Millivolt 22-33,000 BTU Input Direct Vent Fireplace With Black Metal Interior |
|
VVC42NB1
| Natural
Gas
| 42" Millivolt 23-31,000 BTU Input Direct Vent Fireplace With Refractory Brick Lined Interior |
|
VVC42PB1
| Propane
| 42" Millivolt 22-33,000 BTU Input Direct Vent Fireplace With Refractory Brick Lined Interior |
|
VVC42NH1
| Natural
Gas
| 42" Millivolt 23-31,000 BTU Input Direct Vent Fireplace With Herringbone Brick Lined Interior |
|
VVC42PH1
| Propane
| 42" Millivolt 22-33,000 BTU Input Direct Vent Fireplace With Herringbone Brick Lined Interior |
|
|
|
|
|
Optional Remote Control Accessories
|
|
|
|
|
| Model | Description
|
| HRC100 Use Replacement 1001-A | On/Off
Hand Held Remote
(For Millivolt Ignition Models Only)
|
| HRC200 Use Replacement 1001TH-H | Thermostat
Hand Held Remote
(For Millivolt Ignition Models Only)
|
| GWMS2 | Wall Mount On/Off
Switch Kit
(For Millivolt Ignition Models Only)
|
GWMT1
| Thermostat
Wall Switch
(For Millivolt Ignition Models Only)
|
| MRCN | Natural Gas Models Only
Receiver and Hand Held Multi Function Remote Control
Features: programmable flame patterns, adjustable flame height,
programmable thermostat with room temperature display, shut down timer,
optional fan speed, and more!
(For Millivolt Ignition Models Only)
|
| MRCP | Propane Models Only
Receiver and Hand Held Multi Function Remote Control
Features: programmable flame patterns, adjustable flame height,
programmable thermostat with room temperature display, shut down timer,
optional fan speed, and more!
(For Millivolt Ignition Models Only)
|
|
|
|
|
Important Heater Information |
|
|
|
|
- How
A Direct Vent Fireplace Works
- Installation must be done by
qualified
service persons.
- Read Owner's Manual before using.
- Not for use in recreational
vehicles.
- All products approved for
manufactured
(mobile) home installation.
- Heating areas based on rooms with
8'
ceilings.
|
- Operating heater at elevations
above
4,500 ft. could cause
nuisance outages.
- We reserve the right to amend
product
specifications without
notice.
|
|
|
|
|
On/Off (Variable Speed) Manual Squirrel Cage Blower
On/Off/AutoThermostatically Controlled Squirrel Cage Blower
