Vanguard Value Line Direct Vent Gas Fireplace Systems
Vanguard direct vent fireplaces feature brass accent trim and heat circulating louvers with dancing yellow flames and ember materials.
Direct Vent Fireplaces do not affect indoor air quality and are ideally suited for today's energy efficient, tightly constructed homes.




The Value Line Series accept 5" - 8" Desa vent piping.








The Value Line Fireplaces Include:
  • Split oak ceramic fiber gas logs with charred features and glowing highlights
  • "U" tube dual burner to produce impressive dancing flame patterns with glowing embers
  • New York and California only allow installation of electronic ignition models
  • Built on the proven strengths of the 45 degree slant back design
  • Hinged tool-less entry glass door for painless installation, operation, and maintenance
  • All millivolt units feature an adjustable flame control
  • Texture powder coated finish
  • Arch window
  • Hidden screen pockets
  • Flex gas line
  • Shut off valve
  • Pre-wired electrical "J" box to ensure quality, performance, safety, and convenience
  • 1/2" flare connection
  • C.S.A. Approved ANSI Z21.88 / C.S.A. 2.33

Value Line "Tudor" Direct Vent Fireplaces


Accepts 5" x 8" Piping
Model Fuel Type Description
VT32NA1
Natural
Gas
32" Millivolt 12-14,000 BTU Input Direct Vent Fireplace With Stamped Louvers

VT32PA1
Propane
32" Millivolt  11-17,000 BTU Input Direct Vent Fireplace With Stamped Louvers
VT32NRA1
Natural
Gas
32" Millivolt  12-14,000 BTU Input Direct Vent Fireplace With Rolled Louvers
VT32PRA1
Propane
32" Millivolt  11-17,000 BTU Input Direct Vent Fireplace With Rolled Louvers
VT32NBA1
Natural
Gas
32" Millivolt  12-14,000 BTU Input Direct Vent Fireplace With Stamped Louvers With Refractory Brick Lining
VT32PBA1
Propane
32" Millivolt  11-17,000 BTU Input Direct Vent Fireplace With Stamped Louvers With Refractory Brick Lining
VT32NRBA1
Natural
Gas
32" Millivolt  12-14,000 BTU Input Direct Vent Fireplace With Rolled Louvers Refractory Brick Lining
VT32PRBA1
Propane
32" Millivolt 11-17,000 BTU Input Direct Vent Fireplace With Rolled Louvers Refractory Brick Lining





Optional Remote Control Accessories


ModelDescription
HRC100 Use Replacment 1001-AOn/Off
Hand Held Remote

(For Millivolt Ignition Models Only)
HRC200 Use Replacment 1001TH-HThermostat
Hand Held Remote

(For Millivolt Ignition Models Only)
GWMS2 Wall Mount On/Off Switch Kit
(For Millivolt Ignition Models Only)
GWMT1
Thermostat Wall Switch
(For Millivolt Ignition Models Only)
MRCNNatural Gas Models Only
Receiver and Hand Held Multi Function Remote Control
Features: programmable flame patterns, adjustable flame height, programmable thermostat with room temperature display, shut down timer, optional fan speed, and more!
(For Millivolt Ignition Models Only)
MRCPPropane Models Only
Receiver and Hand Held Multi Function Remote Control
Features: programmable flame patterns, adjustable flame height, programmable thermostat with room temperature display, shut down timer, optional fan speed, and more!
(For Millivolt Ignition Models Only)





Vanguard 32" Firebox Mantels


32" Cabinet Mantels
Model Description
CMA305U
32" Unfinished Cabinet Mantel & Base With Black Perimeter Trim ( Shown With Platinum Perimeter Trim)
W32EOS

32" Oak Stained Cabinet Mantel & Base With Black Perimeter Trim, Traditional Design
W32ELS
32" Finished Lyptus Cabinet Mantel & Base With Black Perimeter Trim, Traditional Design
GMC90FA
32" Oak Stained Cabinet Mantel With Columns & Base With Black Perimeter Trim
CMA311W
 32" White
Cabinet Mantel & Base With Black Perimeter Trim, Federal Design
W32GLS
32" Finished Lyptus Cabinet Mantel & Base With Black Perimeter Trim, Mission Design
CMA312FA

32" Oak Stained Cabinet Mantel & Base With Black Perimeter Trim, Classic Design
CMA312FLS

32" Finished Lyptus Cabinet Mantel & Base With Black Perimeter Trim, Classic Design
W32IP

32" White Cabinet Mantel With Click-N-Brick Surround & Base, Federal Design
32" Corner Mantels
ModelDescription
C32GLS
32" Finished Lyptus Corner Mantel & Base With Black Perimeter Trim, Mission Design
C32HLS
32" Finished Lyptus Corner Mantel & Base With Black Perimeter Trim, Classic Design





Vanguard 32" Fireplace Accessories


Blowers
Model Description
BKOn/Off (Variable Speed) Manual Squirrel Cage Blower
BKTOn/Off/AutoThermostatically Controlled Squirrel Cage Blower
Hood
(2" Brow)
ModelDescription
HD3232" Black Firebox Hood

32" Firebox Perimeter Trim
ModelDescription
PT32
 32" Black
Perimeter Trim Kit
(Covers unfinished edges around firebox)

PT32B 32" Brushed Brass
Perimeter Trim Kit
(Covers unfinished edges around firebox)
PT32PB 32" Polished Brass
Perimeter Trim Kit
(Covers unfinished edges around firebox)
PT32P 32" Platinum
Perimeter Trim Kit
(Covers unfinished edges around firebox)





Important Heater Information


  • How A Direct Vent Fireplace Works
  • Installation must be done by qualified service persons.
  • Read Owner's Manual before using.
  • Not for use in recreational vehicles.
  • All products approved for manufactured (mobile) home installation.
  • Heating areas based on rooms with 8' ceilings.
  • Operating heater at elevations above 4,500 ft. could cause nuisance outages.
  • We reserve the right to amend product specifications without notice.
