Vanguard Value Line Direct Vent Gas Fireplace Systems
Vanguard
direct vent fireplaces feature brass accent trim and heat circulating
louvers with dancing yellow flames and ember materials.
Direct Vent Fireplaces do not affect indoor air quality and are ideally
suited for today's energy efficient, tightly constructed homes.
The Value Line Series accept 5" - 8" Desa vent piping.
The Value Line Fireplaces Include:
- Glowing ceramic fiber logs and glowing embers
- Ddual burner to produce impressive dancing flame patterns with glowing embers
- New York and California only allow installation of electronic ignition models
- Dedicated top-vent or rear-vent models
- Hinged tool-less entry glass door for painless installation, operation, and maintenance
- 36" units are Remote ready
- Texture powder coated finish
- Pre-wired electrical junction box for convienient installation
|
|
Value Line "Tudor" Direct Vent Fireplaces
|
|
|
|
|
Accepts 5" x 8" Piping
Click Here For Vent Kits & Vent Piping Accessories
|
| Model |
Fuel Type |
Description |
|
VCD36RN
| Natural
Gas
| 36" Millivolt 15,000-20,000 BTU Input Direct Vent Fireplace With Rear Vent
|
|
VCD36RP
| Propane
| 36" Millivolt 14-20,000 BTU Input Direct Vent Fireplace With Rear Vent |
|
VCD36TN
| Natural
Gas
| 36" Millivolt 15,000-20,000 BTU Input Direct Vent Fireplace With Top Vent |
|
VCD36TP
| Propane
| 36" Millivolt 14-20,000 BTU Input Direct Vent Fireplace With Top Vent |
|
|
|
|
|
Optional Remote Control Accessories
|
|
|
|
|
| Model | Description
|
| HRC100 Use Replacment 1001-A | On/Off
Hand Held Remote
(For Millivolt Ignition Models Only)
|
| HRC200 Use Replacment 1001TH-H | Thermostat
Hand Held Remote
(For Millivolt Ignition Models Only)
|
| GWMS2 | Wall Mount On/Off
Switch Kit
(For Millivolt Ignition Models Only)
|
GWMT1
| Thermostat
Wall Switch
(For Millivolt Ignition Models Only)
|
| MRCN | Natural Gas Models Only
Receiver and Hand Held Multi Function Remote Control
Features: programmable flame patterns, adjustable flame height,
programmable thermostat with room temperature display, shut down timer,
optional fan speed, and more!
(For Millivolt Ignition Models Only)
|
| MRCP | Propane Models Only
Receiver and Hand Held Multi Function Remote Control
Features: programmable flame patterns, adjustable flame height,
programmable thermostat with room temperature display, shut down timer,
optional fan speed, and more!
(For Millivolt Ignition Models Only)
|
|
|
|
|
Vanguard 36" Firebox Face Mantels (Flush Mantels)
|
|
|
|
|
Traditional Design
|
| Model |
Description |
|
| FM36AP |
36" Primed Face Mantel, Traditional Design
|
|
| FM36AU |
36" Unfinished Face Mantel, Traditional Design |
| FM36AO
|
36" Oak Stained Face Mantel, Traditional Design |
Federal Design
|
| Model | Description
| |
| FM36BP | 36" Primed Face Mantel, Federal Design
| |
| FM36BU | 36" Unfinished Face Mantel, Federal Design
|
| FM36BO
| 36" Oak Stained Face Mantel, Federal Design |
Classic Design
|
| Model | Description
| |
| FM36CP | 36" Primed Face Mantel, Classic Design
|
|
| FM36CU | 36" Unfinished Face Mantel, Classic Design
|
| FM36CO
|
36" Oak Stained Face Mantel, Classic Design |
| FM36CL | 36" Lyptus Face Mantel, Classic Design
|
|
|
|
|
Important Heater Information |
|
|
|
|
- How
A Direct Vent Fireplace Works
- Installation must be done by
qualified
service persons.
- Read Owner's Manual before using.
- Not for use in recreational
vehicles.
- All products approved for
manufactured
(mobile) home installation.
- Heating areas based on rooms with
8'
ceilings.
|
- Operating heater at elevations
above
4,500 ft. could cause
nuisance outages.
- We reserve the right to amend
product
specifications without
notice.
|
|
|
|
|
36" Oak Stained Cabinet Mantel & Base With Black Perimeter Trim, Traditional Design
On/Off (Variable Speed) Manual Squirrel Cage Blower
On/Off/AutoThermostatically Controlled Squirrel Cage Blower
